A8000
- Available in three standard sizes.
- 1000 mm, 1200 mm or 1300 mm wide entrances.
- Optional one hour steel fire rated doors.
- Doors and shaft powder coated to any standard RAL colour.
- Glazed shaft option available.
- Lifting beam required.
- 130 mm floor recess required.
- No separate machine room or control box required.
- Automatic LED shaft lighting to reduce power consumption.
- One-touch landing call buttons.
- All control buttons are tactile.
- Travel (maximum): 3000 mm (maximum of 13 m floor to floor travel).
- Number of floors (maximum): Two - ground and first floors (maximum of six different entrance levels).
- Screw and rotating nut driven by 4.0 kW 'variable frequency' motor.
- Includes ceiling with automatic lighting.
- Smooth moulded anodized aluminium handrail fitted to console.
- One touch control from landings with red/ green halo illumination.
- Push buttons: Large easy to use tactile push buttons.
- Audible indication: Voice announcer informs of lift arrival.
- Emergency lowering: Battery operated emergency lowering.
- Overload: Protection with visual and audible indication.
- Safety edges: Fitted around sides of platform and above the carriage.
- Headroom: 2400 mm.
- Pit depth: 130 mm, or can be used with provided ramp.
